Dual-light Binoculars 50mm
Handheld Devices
Dual-light Binoculars 50mm
This product is a multi-functional dual-light binoculars equipped with a laser rangefinder, integrated GPS and electronic compass data capabilities. It supports photo/video capture with playback functions, and features a built-in Wi-Fi hotspot for real-time video streaming to connected smartphones or other devices. Additionally, it has a simulated CVBS output for connecting to analog monitors to display video. Suitable for various observation scenarios such as nature observation, outdoor exploration, security surveillance, maritime operations, and night patrols.
Detection Range
- Human (1.7m)
- 2500m detection / 800m recognition
- Vehicle (2.3m)
- 3600m detection / 1200m recognition
Key Features
- Shutterless image, low power consumption, quick startup
- Multifunctional USB, supporting UVC, MTP, and ADB functions
- Dual vision fusion function
- Laser distance measurement (1200m for vehicles, 500m for standing human)
- GPS and electronic compass data overlay
- WiFi hotspot for real-time streaming
- Simulated CVBS Output
- Support AI human-vehicle recognition
- 32G TF Card for snapshot and recording
Technical Specifications
| NETD | ≤35mk |
|---|---|
| Weight | 1110g |
| Display | Binocular OLED, 0.39", 1024×768 |
| Palette | 5-mode false color imaging |
| IP Rating | IP67 |
| Dimensions | 210mm × 135mm × 70mm |
| Thermal FOV | 8.8°×7.0° |
| Visible FOV | 17.7°×10.1° |
| Power Supply | 21700 Lithium Battery (1 Cell) |
| Thermal Lens | 50mm F1.0 |
| Operating Time | 4 hours (Normal Temp.) |
| Electronic Zoom | 2×, 4×, 8× |
| Operating Temp. | -20°C ~ +60°C |
| Thermal Detector | Uncooled Vox, 640×512, 12μm |
| Visible Light Lens | 25mm |
| Visible Light Sensor | Low-light CMOS, 1/1.8", 4MP |
Technical support scope is confirmed according to order requirements. Specifications are subject to change without notice.
